Lens
2.7 mm to 13.5 mm motorized vari-focal lens
Horizontal Field of View
108.1° to 45.6°
Lens Mount
Φ 14
Day & Night
IR cut filter
Synchronization
Internal synchronization
Angle Adjustment
Pan: 0° to 360°; Tilt: 0° to 75°; Rotate: 0° to 360°
Image Sensor
8.29 megapixel progressive scan CMOS
Frame Rate
TVI: 8MP@12.5fps, 8MP@15fps, 5MP@20fps, 4MP@25fps, 4MP@30fps, 2MP@25fps,,2MP@30fps,CVI: 8MP@12.5fps, 8MP@15fps,AHD: 8M@12.5fps, 8M@15fps,CVBS: 960H P/N
Resolution
3840 (H) × 2160 (V)
Min. illumination
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/12.5s to 1/50, 000 s,NTSC: 1/15 s to 1/50, 000 s
Switch Button
TVI/AHD/CVI/CVBS
Video Output
1 HD analog output
Weight
Approx. 580 g (1.28 lb.)
Operating Condition
-40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply
9 VDC to 15 VDC,*You are recommended to use one power adapter to supply the power for one camera.
Power Consumption
Max. 8.6W
Protection Level
IP67
Material
Metal
IR Range
Up to 60 m
Communication
Up the coax, Protocol: HIKVISION-C (TVI output)
Dimensions
134.3 mm × 123.86 mm × 110.24 mm (5.29" × 4.88" × 4.34")
