IP Video Input
16-ch
Incoming/Outgoing Bandwidth
160 Mbps
HDMI Output
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Output
1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio Input
1-ch, RCA (2.0 Vp-p, 1kΩ)
Decoding Format
H.265/H.265+/H.264/H.264+/MPEG4
Recording Resolution
8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Synchronous Playback
16-ch
Capability
2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps)
Network Protocols
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
Network Interface
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
Interface
16, RJ-45 10/100 Mbps self-adaptive Ethernet interface
Power
≤ 200 W
Supported Standard
IEEE 802.3 af/at
SATA
2 SATA interfaces
Capacity
Up to 6 TB capacity for each HDD
USB Interface
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm In/Out
4/1
Weight (Without Hard Disk)
≤ 3 kg (6.6 lb)
Power Supply
100 to 240 VAC,≤ 280 W
Consumption (Without HDD)
≤ 15 W (without enabling PoE)
Working Temperature
-10 °C to 55 °C (14 °F to 131 °F)
Working Humidity
10 to 90 %
Dimensions (W × D × H)
385 × 315× 52 mm (15.2" × 12.4" × 2.0")
